Full-auto Hemoglobin Analyzer

FOB Price : Get a Price/Quote

Min.Order : 1 Set(s)

Certification : CFDA,GMP,ISO9001,ISO13485,CE,FDA

Brand Name : MeCan

Payment Terms : T/T,WesternUnion,MoneyGram,Others

favorite

share :

product information

  • brand name : MeCan

  • certification : CFDA,GMP,ISO9001,ISO13485,CE,FDA

  • min.order : 1 Set(s)

  • warranty :

  • payment terms : T/T,WesternUnion,MoneyGram,Others

  • Packaging :

  • Specification :

  • place of origin : unknown

product description

Model: MCL-PT06                                                            Certification: /

Dimension: Weight 8KG                                                   Packaging Details: /

Brand Name: MeCan                                                        Place of Origin: Guangdong, China (Mainland)

Warranty: /                                                                       Color: /

Size: 408*390*230mm                                                      Finish: /

Customer's Logo: /                                                          MOQ: 1 set

Processing Time: 3-15 working days                               Usage: /

Quality: /                                                                          Packaging: standard export package

Full-auto Hemoglobin Analyzer
MCL-PT06

What is the feature of our Full-auto Hemoglobin Analyzer?

Precision Chromatographic Column and Thermostatic Apparatus
Precision chromatographic column and reagent thermostatic control apparatus ensure that Chromatographic column and reagent are not affected by environment temperature and effectively guarantees the repeatability and correctness of the test results
Supply with Original Calibrator
The international standard value tracing is adopted. The authoritative reference material for quality control is used to transfer the numeric value. Each set of reagent is supplied with two sets of calibrator for proper calibration so as to ensure that the test results are correct and reliable and thoroughly to avoid individual error caused by factor calibration.
High Sensitivity 415nm LED Integral Photometer
High sensitivity 415nm LED integral photometer has the characteristics of correct wavelength, stable light source, full aluminum alloy structure, high anti-interference performance, multi-lens focusing, micro cuvettes and high sensitivity. It can record accurately analysis curve.
High Separation Liquid Chromatographic Column
High separation liquid chromatographic column made of imported resin with volume of Φ 9mm x 45mm and weight of 2.5g which is 15 – 20 times greater than general micro chromatographic column. High efficiency chromatographic column for 300 tests ensure the accuracy of test results.
Testing Method   Low pressure ion exchange liquid chromatography
Testing Item Glycated hemoglobin HbA1c
Testing Scope 3%-18%
Testing Parameters Precision(CV)≤3%, Accuracy(V) ≤1.50%
Testing Time 4 minutes(reporting), Full-processing 6 minutes(including cleaning column and recovery time)
Sample Type Venous blood(EDTA anticoagulation), Peripheral finger blood
Sample Volume      5ul Whole blood for each sample
Functional Parameters
Photometer 415nm LED Integral flow colorimeter
Sampling mode Fully-auto 20 position sample turntable
Testing mode Auto test for batch, single test for emergency
Calibration Optional selection of 2 points or 4 points calibration, optional selection of manual or automation, Equipped with 2 groups of high and low level calibrators
Thermostatic control Column and reagent thermostatic control: 25 ±0.5℃
Reagent matching One piece of column and reagent consumable/300 pieces of testing samples
Reagent allocation Each standard package inclues A, B, C, D eluent, calibrator, hemolytic agent, pump tubing
Output Parameters
Display 320×240 LC Graphic display, displaying real-time testing curve
Printer 58nm Thermal printer, printing testing curve and report
Report Output   IFCC concentration value, NGSP area percentage, ADAG average glucose
Data storage 1000test report(including testing curve)
Communication interface RS232 communication interface, connecting to HIS/LIS system
Working Parameters
Power Supply AC220V±22V, 50HZ, 65VA
Size 408*390*230mm
Weight 8KG
Working Environment Temperature 12-30℃, Relative humidity ≤85%
