Diaphragm liquid pump KLP04

FOB Price : Get a Price/Quote

Min.Order : 1 Set(s)

Certification : CFDA,GMP,ISO9001,ISO13485,CE,FDA

Brand Name : Kamoer

Payment Terms : L/C,T/T,PayPai,WesternUnion,MoneyGram,Others

favorite

share :

product information

  • brand name : Kamoer

  • certification : CFDA,GMP,ISO9001,ISO13485,CE,FDA

  • min.order : 1 Set(s)

  • warranty :

  • payment terms : L/C,T/T,PayPai,WesternUnion,MoneyGram,Others

  • Packaging :

  • Specification :

  • place of origin : China

product description

Model: KLP                                                                     Certification: CE,FDA&ROHS

Packaging Details: Carton                                              Brand Name: Kamoer

Place of Origin: Shanghai,China                                     Warranty: 1 year

Color: Blue,black,green and yellow                                Size: 59.5mm*24mm

Finish:-                                                                            Customer's Logo:-

MOQ:1 PC                                                                       Processing Time: Receive payment immediately(reply on the quantity)

Usage: Medical,Chemical,Laboratory and Factory         Quality: Meet standards

Packing: 170mm*130mm*120mm

FEATURES:
  1. Compact size
  2. Low vibration
  3. Low noise
  4. Chemical resistant materials available
  5. Oil-free. No contamination
  6. Life up to 10,000 hours
  7. Pulse Width Modulation is available
 TECHNICAL DATA:
  1. Flow (mL/min): 320
  2. Pressure (PSI): 7.0
  3. Voltage (DC): 12/24
  4. Power (mA): 250/150
  5. Weight (g): 40
  6. Dimensions (mm): 50×25 Ø
PLEASE NOTE:

Pulse Width Modulation (PWM) option is available on certain DC volt version pumps. This unique feature is highly desirable for applications requiring precise control of the pump output.

WIRING INSTRUCTIONS FOR BRUSHLESS MOTOR:

RED: +ve
BLACK: -ve
WHITE: PWM (Pulse Width Modulation) 5-20 kHz, 0-5 V
* Black and White wires may be joined together if PWM function is not needed.



Kamoer Fluid Tech (Shanghai) Co., Ltd

Ordinary verified

Business Type Manufacturer

Country / Region Shanghai,China

Main Products Medical Accessories

Main Markets European and American market

Diaphragm liquid pump KLP04
share :

product information

product description

Model: KLP                                                                     Certification: CE,FDA&ROHS

Packaging Details: Carton                                              Brand Name: Kamoer

Place of Origin: Shanghai,China                                     Warranty: 1 year

Color: Blue,black,green and yellow                                Size: 59.5mm*24mm

Finish:-                                                                            Customer's Logo:-

MOQ:1 PC                                                                       Processing Time: Receive payment immediately(reply on the quantity)

Usage: Medical,Chemical,Laboratory and Factory         Quality: Meet standards

Packing: 170mm*130mm*120mm

FEATURES:
  1. Compact size
  2. Low vibration
  3. Low noise
  4. Chemical resistant materials available
  5. Oil-free. No contamination
  6. Life up to 10,000 hours
  7. Pulse Width Modulation is available
 TECHNICAL DATA:
  1. Flow (mL/min): 320
  2. Pressure (PSI): 7.0
  3. Voltage (DC): 12/24
  4. Power (mA): 250/150
  5. Weight (g): 40
  6. Dimensions (mm): 50×25 Ø
PLEASE NOTE:

Pulse Width Modulation (PWM) option is available on certain DC volt version pumps. This unique feature is highly desirable for applications requiring precise control of the pump output.

WIRING INSTRUCTIONS FOR BRUSHLESS MOTOR:

RED: +ve
BLACK: -ve
WHITE: PWM (Pulse Width Modulation) 5-20 kHz, 0-5 V
* Black and White wires may be joined together if PWM function is not needed.
